EV800D vs EV800DM
|
Comparison |
EV800D |
EV800DM |
|
Weight |
362g without antenna |
320g without antenna |
|
DVR |
720*576px |
720*576px |
|
Diversity |
Yes |
Yes |
|
Screen size |
5.0 inch |
3.0 inch |
|
Screen resolution |
800*480 |
900*600 |
|
Ratio |
16:9, 4:3 |
4:3 |
|
Separable Design |
Removable screen, can be used as a monitor. |
NO |
|
Support Tripod |
Yes, with 1/4 inch screw hole |
NO |
|
Varifocal |
NO |
20mm focal length adjustable; |
|
Glasses Fit |
NO |
Fit for wear with 140mm*40mm glasses; |
|
Battery |
7.4V/1200mAh or |
3.7V/2000mAh |
Features:– Built-in with super HD DVR up to 720*576px resolution- Diversity RaceBand 40ch Auto-Searching – Two system (Display/rec0rd duo core separated chipsets ) ensure no delay in displaying and no frame lost in recording(please use C10 speed card to ensure the full frame rec0rding)– Work friendly with player-OSD, no block on the important flying OSD information;– Focal length adjustable design;Room for eyeglasses– HD high brightness 3 inch LCD specially tuned for FPV racing;- Diversity function, Built-in super sensitive 5.8GHz 40ch receiver module, with RaceRand;- Advanced auto-searching function and the working frequency show on screen;- Built-in 3.7V 2000mAh battery, each full charge offer 2.2 hours working time;– Wide rang re-charge voltag 5-18V;– Accept 2S or 3S batteries as back-up power source, to prolong the working time;- Nice ergonomic design and fit different faces;- Super-wide visible angle up to 82 degree;- 92% transparent lens adopted, no distort, no blur on the edge of screen;- Light weight 320g with 2.2 hr 2000mAh battery, RTF for any scale racing game;- 3 Inch 900*600px HD high brightness LCD
Description :Brand Name : EACHINEItem Name : EV800DM
English Manual：Click here
| Appearance | Dimension: 150*170*80mmWeight: 320g without antennaBelt : three-way adjustable belt |
| Specification | Build in DVRrec0rd up to 720*576px full frame rate video, no frame lost (C10 card required)Riplay in MENURequire C10 card to rec0rd full frame rate |
| Diversity | – 90dB Super sensitiveness in 2pcs RX5808 PRO modulesGreat performance when two types (Linear and Omni) antennas are used |
| Display | Screen size: 3.0 inchScreen resolution: 900*600(No blur after enlarge by the lens)Screen brightness: 600cd/m2 with special high brightness backlight LED for outdoor FPVRatio : 4:3View Angle: 140/120 degree(Horizontal/Vertical) |
| Lens | 3x boost of the video to acquire intense feel-in-there video;92% transparent rate distort if light; |
| Varifocal | 20mm focal length adjustable;Multi stop points design for vertical individual user adjust;For more users with different eyesight |
| Glasses Fit | Fit for wear with glasses;Glasses Fit Size; 140mm*40mm;Focal length need to be reset when wear glasses |
| Battery | Built-in 3.7V/2000mAh battery;Each battery circle offer around 2.2hr working time;5-20V wide rang recharging voltag rang, typical recharging with 5V/2ACharger : 5V, 2A, DC 2.5mm2S (7.4 V) /3S(11.1V) battery as back-up power t to have long working time. |
Frequencies (5.8GHz, with RaceBand)
| CH | CH 1 | CH 2 | CH 3 | CH 4 | CH 5 | CH 6 | CH 7 | CH 8 |
| GROUP | ||||||||
| A or FR1 | 5865 MHZ | 5845 MHZ | 5825 MHZ | 5805 MHZ | 5785 MHZ | 5765 MHZ | 5745 MHZ | 5725 MHZ |
| B or FR2 | 5733 MHZ | 5752 MHZ | 5771 MHZ | 5790 MHZ | 5809 MHZ | 5828 MHZ | 5847 MHZ | 5866 MHZ |
| C or FR3 | 5705 MHZ | 5685 MHZ | 5665 MHZ | 5645 MHZ | 5885 MHZ | 5905 MHZ | 5925 MHZ | 5945 MHZ |
| D or FR4 | 5740 MHZ | 5760 MHZ | 5780 MHZ | 5800 MHZ | 5820 MHZ | 5840 MHZ | 5860 MHZ | 5880 MHZ |
| R or FR5 | 5658 MHZ | 5695 MHZ | 5732 MHZ | 5769 MHZ | 5806 MHZ | 5843 MHZ | 5880 MHZ | 5917 MHZ |
Recommanded Parts
FPV VTX : 5.8Ghz VTX Click Here
Small Camera : Click Here
Spare Battery Box : Click Here
Package Included :
1 x EV800DM 40CH 5.8G Varifocal FPV Diversity Goggles with DVR
1 x Clover Antenna
1 x Panel Antenna
1 x Battery Charger
1 x USB Power Charging Cable
1 x AV In/Out cable
1 x User Manual
