Features:
1. Double-sided fully wrapped CNC shell, efficient heat dissipation, isolation of foreign matter.
2. Dual MOS parallel solution, supports 90A continuous current, can withstand up to 100A peak current.
3. Support BL32 ESC telemetry, more stable ESC firmware, real-time monitoring of ESC parameters.
4. High-performance MCU G071, operating frequency up to 64MHz.
Specification：
Brand: HGLRC
Model: SPECTER
Item Name: 90A 2-8S Single ESC / 5V 12V BEC Distribution Board
| Name |
Specification |
| HGLRC SPECTER 90A Single ESC |
Continuous Current: 90A |
| Instantaneous Current: 100A |
|
| MCU: STM32G071 |
|
| Input Voltage: 2-8S |
|
| BEC: None |
|
| Temperature Protection: Supported |
|
| ESC Telemetry: Supported |
|
| Drive Signal Support: Dshot150, Dshot300,Dshot600, Oneshot, Multishot |
|
| Firmware Version: 32.9 BLheli_32 |
|
| Frame Vize: 39mm*19.6mm*8.34mm |
|
| Weight:13.9g |
|
| Distribution Board |
Number of ESCs Supported: 8 |
| Telemetry Feedback: Supported(ESCs need to support telemetry feedback) |
|
| 5V BEC: 5A |
|
| 12V BEC: 4A |
|
| Amperemeter: Supported |
|
| PCB Current: continuous 4*100A (instantaneous 120A) |
|
| Frame Size: 50mm*50mm*9.8mm |
|
| Hole Size: 30.5mm*30.5mm/m3 |
|
| Weight: 24g (±2g) |
Package Included:
| Item Name |
Included |
| HGLRC SPECTER 90A single ESC |
1x HGLRC SPECTER 90A ESC |
| 1x 50V 470UF Solid Capacitor |
|
| 1x Black, Green and Yellow 30AWG Silicone Wire 20cm |
|
| Distribution Board |
1x Distribution Board |
| 1x Extra Soft High and Low Temperature Resistant Silicone Wire, 30AWG, 70mm, Single Head GH1.25-12P/Single Head SH1.0-8P |
|
| 1x 50V 470UF Solid Capacitor |
