Specifications:
| Frequency： | 5.3GHz-6GHz |
| MAX Gain： | 2.65dbi（5695MHz) |
| MIN Gain： | 2.06dbi（5362MHz) |
| AVGGain： | 2.4dbi |
| MAX VSWR： | 1.76（5917MHz) |
| MIN VSWR： | 1.46（5621MHz) |
| AVGVSWR： | 1.75 |
| MAX radiation efficiency： | 86%（5436MHz) |
| MIN adiation efficiency： | 76%（5917MHz) |
| AVGadiation efficiency： | 83% |
| Polarization： | LHCP/RHCP |
| Cross polarization suppression： | -25dB |
| Axial Ratio： | ≤ 3 |
| Cable： | RG141 |
| Weight： | 9.5g |
| Total Length: | 100mm |
| Connector： | SMA /RP-SMA |
Features:
– High-quality SMA antenna for optimal signal strength and transmission.
– 100mm length for easy installation and compatibility with various setups.
– Available in both LHCP and RHCP configurations to suit different needs.
– Tough construction for long-lasting performance and protection against damage.
– Enhances video transmission and reception for an improved FPV experience.
Package Included:
100mm LHCP/RHCP Antenna
