iFlight XING 2806.5 1300KV 1800KV 3-6S Cinelifiter Brushless Motor for AOS7 EVO Chimera7 Pro 7Inch to 8 Inch FPV Racing RC Drone

0 out of 5

$29.99

SKU: POA0004765 Categories: , ,
Add to wishlist

Description

Introduction:
The Motor XING 2806.5 designed for bigger quads like 7-8 inch quad frames, which is with better efficiency in this range frames.The XING 2806.5 features uni-bell design and adopt Japan NSK bearing, N52H arc magnets. It offers incredible thrust number, highly responsive and extremely smooth flight characteristics. The bigger stator size 2806.5 allows it to provide instant power to save you from those crazy mountain dives last minute. It’s a great motor if you’re building bigger drones like 7 inch or 8 inch.

Specification:
Brand: iFlightModel: XING 2806.5

Item Name:  2806.5 1300KV 1800KV 3-6S Brushless Motor

Optional KV: 1300KV / 1800KV

Weight(included wire):54.3g/53.3
Dimension: φ35.06*21.3mm
Interphase Resistance:72.29mΩ/ 45.5mΩ
Input Volts: 24V
Peak Current: 48.33A/72.3A
Max Watt: 1132.9W/1681.0W
Mounting Holes: 19*19 φ3mm
Rotor Specifications:  Unibell
Shaft Diameter: 5mm/4mm
Shaft Protruding Length: 15.5mm
Lead: 265mm/18AWG
Magnet: N52H Curved
Configuration: 12N14P
Bearing Type: NSK
Bearing Specification: φ11*φ5*45
Winding: Single Strand copper winding


Test Table & Darwing Picture

1300KV Version / 1800KV Version


Features:

– High-strength 4mm Titanium alloy shaft
– Unibell design
– 7075 aluminum Bell and Base
– Electromagnetically matched magnets and stator
– Japanese NSK 11*5*5 bearings
– N52H Arc curve magnets
– Motor wires protected
– Hex bolt shaft set screw
– Dynamically balanced

Package Included:

1x X2806.5 motor
1x M5 Screw nut
4x M3*8 screws
