SkyRC Q200neo 4 Channel AC 200W DC 400W 10A*4 Multi-Function Smart Charger for 1-6S Lipo LiHV LiFe LiIon 2-15S NiMH NICD Battery

Specifications:

Brand: SkyRC

Model: Q200neo

Size and Weight
Case Material: PC-ABS V0
Case Size: 123*119*78mm
Weight: 680g

Display
Display Type: TN
Size: 2.8 inch
Panel Active Area: 43.20*57.60mm
Resolution: 240×320 Pixel
Number of Colors: 262K

Power
DC Input Voltage: 10-30V
AC Input Voltage : 100-240V

Charger power:
Charge Current: 0.1~10A * 4 Charge Power: DC 100W * 4(400W) AC 200W

Discharge power:
Main port: 5W
Balance port: 25W MAX (LiPo/6S)

20W USB-C Power Delivery:
QC3.0: 5V⎓3A, 9V⎓2A, 12V⎓1.5A 18W
PD: 5V⎓3A, 9V⎓2.2A, 12V⎓1.67A 20W

DC Power Supply
Output Voltage: 1.0-30.0V
Output Current: 0.1-10.0A
Output Power: Max. 100W single port

Battery
Battery Types/Cells:
LiPo/LiHV/LiFe/LiIon: 1-6cells
NiMH/NiCd: 2-15cells
Pb: 3S/6S/12S

Charge and Discharge
Charge current
LiPo/LiFe/LiIon/LiHV/NiMH/NiCd/Pb：0.1-10.0A

Discharge current
LiPo/LiFe/LiIon/LiHV/NiMH/NiCd/Pb：0.1-2.0A

Balance current
LiPo/LiFe/LiIon/LiHV：800mA MAX

Operation
LiPo/LiFe/LiIon/LiHV: Balance CHG, Charge, Storage Discharge
NiMH/NiCd: Charge, Re-Peak, CYCLE_C_D, CYCLE_D_C, Discharge
Pb: Charge, AGM Charge, Cold Charge, Discharge

Features:

Smart Charging Control: Connect via Type-C or Bluetooth and take full control of the charging process with the Charger Master on PC, or smartphone.

Rectifier Circuit Technology: Proprietary design that efficiently converts DC into secure D/C power, backed by an onboard MCU for precise, efficient charging.

Enhanced Safety Measures: In-built protection features for optimal charging safety.

Universal Voltage Input: Hassle-free charging on the go with the universal-voltage input circuit, eliminating the need for voltage converters.

Multi-Language Interface: Easily switch between languages like English, Dutch, Chinese, French, and Japanese for a comfortable charging experience.

Note：

Do not set the DC output to connect the battery. As long as the voltage at the battery end is higher than the set voltage, the charger will be damaged immediately.

Package Included:
1x Skyrc Q200neo Smart Charger
